Place of Origin: | Zhangjiagang,Jiangsu,China |
ชื่อแบรนด์: | HD Boiler |
ได้รับการรับรอง: | ISO9001,ASME,Grade A,SGS,EN |
Model Number: | WNS |
Minimum Order Quantity: | 1Set |
---|---|
ราคา: | Negotiable |
Packaging Details: | Seaworthy Packing |
Delivery Time: | 30 Days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 500 Sets / Per Year |
Condition: | New | Structure: | Fire Tube |
---|---|---|---|
Fuel Available: | Gas-Fired, Oil-Fird, Diesel-Fired | Rated Working Pressure(Mpa): | 1.0-1.25 |
Rated heating capacity: | 1.4-14 (MW) | Rated Steam Temperature: | 184-193 |
Surface Treatment: | Painted | Operation: | Automatic |
Typical User: | Food and Textile and Hotel and Oil Fired | Placemen: | Horizontal Boiler |
Remarkable Energy Saving Effect WNS OIL(GAS) Fired Steam Hot Water Boiler With Fast Installation
Structural features
WNS oil (gas) fired steam hot water condensation boiler. External integrated fin tube type economizer. Independent condenser, compact structure, convenient repair, the energy saving effect is remarkable. Thermal efficiency could 100% according to low calorific value of fuel. At user request, boiler could use PLC control, and reserve interface remotely operated.
The performance advantage
Parameter
Model | WNS 2-1.0-Y,Q | WNS 4-1.25Y,Q | WNS 6-1.25-Y,Q | WNS 8-1.25-Y,Q | WNS 10-1.25-Y,Q | WNS 15-1.25-Y,Q | WNS 20-1.25-Y,Q | |
Rated evaporation capacity(t/h) | 2 | 4 | 6 | 8 | 10 | 15 | 20 | |
Rated working pressure(MPa) | 1.0 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | |
Rated steam temperature | 184 | 193 | 193 | 193 | 193 | 193 | 193 | |
Wear-supply temperature | 20 | 20 | 60 | 60 | 60 | 104 | 104 | |
Boiler volume(m3) | 3.2 | 7.4 | 10.6 | 11.7 | 14.4 | 16.8 | 21.2 | |
Design efficiency(%) | 90 | 90 | 90 | 90 | 90 | 90 | 90 | |
Applicable fuel |
Light oil,heavy oil,natura gas,liquified gas and urban coal gas | |||||||
Extemal size | Lenght A(mm) | 5084 | 6022 | 7151 | 7600 | 8360 | 9050 | 9650 |
Width B(mm) | 2450 | 2700 | 2800 | 3000 | 3000 | 4500 | 5000 | |
Height H(mm) | 2380 | 2684 | 2882 | 3200 | 3200 | 5200 | 5600 | |
Boiler weight (t) | 7.2 | 12.6 | 17.2 | 18.6 | 23.5 | 36.2 | 45.5 | |
Diamater of main steam opening(mm) | 65 | 100 | 125 | 150 | 150 | 200 | 200 | |
Diameter of safety valve(mm) | 40×2 | 50×2 | 65×2 | 65×2 | 80×2 | 100×2 | 100×3 | |
Chimney diamater(mm) | 350 | 450 | 600 | 700 | 750 | 900 | 1000 |
Competitive Advantage
Quality control and management to the whole produce process, including ingot smelting, hot-rolling, heat treatment, machining and strictly final inspection prior to delivery.
Excellent product quality and service, competitive price, “in-time” delivery
